Lågspänningskatalog mini
Megger Sweden
Lågspänningskatalog mini
Publicerad: 7 augusti 2025 · Kategori: Pdf-kataloger
Ur dokumentet
TEST AND MEASUREMENT FROM MEGGER TEST AND MEASUREMENT EN ENGLISH EVT100 ELECTRIC VEHICLE TESTER APPLICATIONS TARGET CUSTOMERS FEATURES Hybrid Electric Vehicles - HEV Battery Electric Vehicle - BEV Plugin Hybrid Electric Vehicles - PHEV Light Electric Vehicles - LEV 2 Wheelers 3 Wheelers 4 Wheelers Manufacturers Garages Repair Centres Maintenance Centres Insurance Companies Crash Investigation Centres Meets UN Regulation 100r3e for Electric Vehicle Testing DC Voltage and polarity test 0 - 1000 V Insulation resistance & surface leakage current detection 100 - 200 G (50 - 1000 V & Guard Terminal Continuity and bonding testing 1 m - 10 (200 mA) includes patented 4 wire Kelvin leads 2 wire continuity testing 0.01 - 1 M (20 mA - 200 mA) Temperature testing and recording Type T Thermocouple 600V Data Storage and Management 256 tests results date & time stamped ADDITIONAL NOTES Low resistance testing with four terminals Used for detecting critical changes in electric and mechanical bonding metal components, frame structures, equipotential points to earth, and lightning protective conductors. Tests are performed at 200mA dc. Insulation testing with three terminals Used for measuring the electrical separation of conductive parts or conductors from earth, and the condition of insulating materials. It can test insulation resistance from 100 up to 200 G, with test voltages of 50 V, 250 V, 500 V, 1 kV. Diagnostic insulation tests A good insulation resistance values means a relatively...
Öppna PDF:en
